PLOT 6200FZ Fresnel Light with 200W RGBALC 6in1 Led and Motorized Zoom

Download product sheet

Centolight PLOT 6200FZ is a LED Fresnel Light with adjustable light beam from 15° and 50° via motorized zoom. The light source consists of a 200W 6-color Led (Red, Green, Blue, Amber, Lime and Cyan) whose color combination, as well as offering unmatched color palette compared to previous RGBW and RGBWA technologies, allows white color temperature adjustment fr... Read more

Centolight PLOT 6200FZ is a LED Fresnel Light with adjustable light beam from 15° and 50° via motorized zoom. The light source consists of a 200W 6-color Led (Red, Green, Blue, Amber, Lime and Cyan) whose color combination, as well as offering unmatched color palette compared to previous RGBW and RGBWA technologies, allows white color temperature adjustment from warm (about 2000°K) to cold (about 8500°K). The result is a Fresnel light suited to any application (theater, shows, fixed installations, etc.) also thanks to the motorized zoom controlled via DMX with 15° - 50° beam angle.

The dimmer control is extremely accurate and, because of the high refresh frequency (over 15kHz), it is flicker-free and can also be used in television contexts. The quality of the Fresnel lens makes the light beam very diffused and smooth.

Low noise is guaranteed by the quality of cooling fan and as well as the internal processor that allows the best balance between LED temperature and fan noise, always within 20dB @ 1m. The fixture is equipped with rotatable barndoor.

Collapse text

Product downloads

Media

Media

Highlights

RGBALC 6-color Led Technology

The addition of Amber, Lime and Cyan to RGB basic colors allows infinite color palette and to adjust the white temperature from 2000°K up to 8500°K.

Fan noise reduction

The control of the fan speed according to Led temperature always keeps fan noise under 20dB (about 1m away).

RGBALC Led Technology
Fan Controlled by Processor
DMX-512 Control
Flicker-Free Operation
Zoom
RDM Communication

Product details

Key features

  • LED Fresnel Light with 15°-50° Motorized Zoom
  • 200W RGBALC 6in1 LED with over 50,000h lifetime
  • Color Temperature ranging from 2000°K up to 8500°K
  • Ø130mm (5.1in) Fresnel Lens
  • Zoom Range from 15° to 50°
  • Up to 5630lux @ 3m
  • CRI ≥90
  • Smooth 16-bit Dimmer
  • Flicker-Free Operation
  • Low-Noise Cooling System
  • Rotatable Barndoor Included
  • More Less

Specifications

  • Light Source
    1x200W RGBWALC 6in1 COB LED
  • Zoom
    Motorized from 15° to 50° (DMX or Manually Controlled)
  • Chip Life
    Over 50,000h
  • Fresnel Lens
    Ø130mm (5.1in)
  • CCT (Color Temperature)
    from 2000°K to 8500°K
  • CRI
    Ra≥90
  • Flicker-Free
    LED frequency over 15.000Hz
  • Beam Angle
    15°-50°
  • Lens Material
    High-Quality Glass Fresnel Lens
  • Dimmer
    16-Bit Smooth Linear Dimming
  • Strobe effect
    Yes
  • Cooling System
    Quite Fan (under 25dB @1m) + Copper Tube
  • DMX Channel Modes
    12 Channels (RDM Included)
  • Control Modes
    DMX, Strobo, Master-Slave, Manual Dimming
  • Control Panel
    4 Buttons and LED Display
  • IP rate
    IP20
  • DMX In/Out
    3-pin XLR
  • Power Socket
    Powercon In/Out
  • Voltage
    100~240V 50/60Hz
  • Fuse
    F5AL/250V (5x20mm)
  • Max Power Consumption
    220W
  • Working Temperature
    -30÷55 °C (-22÷171 °F)
  • Barndoor
    Rotatable Barndoor (Included)
  • Fixture Size (WxDxH)
    400x187x220 mm – 17.75x7.36x8.66 in (only fixture, without barndoor and C-Bracket)
  • Net Weight
    6,6kg – 14.55 lbs.
  • Packing Size (WxDxH)
    540x280x280 mm – 21.26x11.02x11.02 in
  • Packing Weight
    7,6kg – 16.75 lbs.
